Step 1: Copy the curl Command from the UI
On the Export (Dump) Database page for your MongoDB node, click { REST API }. You’ll copy a command such as:

curl -v \
  -H "Authorization: Bearer <YOUR_JWT_TOKEN>" \
  -H "Content-Type: application/json" \
  -H "Accept: application/json" \
  -d '{
    "node_id":     "<MONGO_HOST_ADDRESS>:<MONGO_HOST_PORT>",
    "schedule":    false,
    "compress":    false,
    "backup_path": "<BACKUP_PATH>",
    "keep_days":   3,
    "rest_api":    true
  }' \
  <API_BASE_URL>/backup_mongo_node/

Step 2: Parse the curl Command

• Authorization header:
  Extract the JWT token after Bearer.
• Content-Type & Accept:
  Both must be application/json.
• Payload fields:
  • node_id (string, format: <host>:<port>)
  • type (string, e.g., "MONGO")
  • cluster_id (string, unique cluster identifier)
  • schedule (boolean, if export is scheduled)
  • compress (boolean, whether to compress export)
  • include_data (boolean, include actual data or only schema)
  • export_path (string, path to save export)
  • keep_days (integer, days to retain export files)
  • rest_api (boolean)
• Endpoint:
  • Base URI: <API_BASE_URL>
  • Resource path: /dump_mongo_node/

‍

Step 3: Translate into Terraform

• Create directory & file:

integration/
└── terraform/
    └── export_database/
        └── main.tf

• Provider block

// Terraform configuration for automating MongoDB node export (dump) on 123cluster
terraform {
  required_providers {
    restapi = {
      source  = "Mastercard/restapi"
      version = "1.19.1"
    }
  }
}

/*
  REST API provider configuration:
  - uri: Base API endpoint for 123cluster.
  - headers: JWT and content type.
  - write_returns_object: Output as object.
  - debug: Enables logging for troubleshooting.
  - HTTP methods: POST for all actions.
*/
provider "restapi" {
  uri                  = "<API_BASE_URL>"
  write_returns_object = true
  debug                = true
  headers = {
    Authorization = "Bearer <YOUR_JWT_TOKEN>" // Use a valid, secure JWT token
    Content-Type  = "application/json"
    Accept        = "application/json"
  }
  create_method  = "POST"
  update_method  = "POST"
  destroy_method = "POST"
}

• Variable declarations

/*
  Use variables for all environment- and user-specific values.
*/

variable "mongo_host_address" {
  description = "Address (IP or FQDN) of the MongoDB host"
  type        = string
  default     = "<MONGO_HOST_ADDRESS>"
}

variable "mongo_host_port" {
  description = "Port on which MongoDB is listening"
  type        = string
  default     = "<MONGO_HOST_PORT>"
}

variable "cluster_id" {
  description = "Cluster identifier for the MongoDB cluster"
  type        = string
  default     = "<CLUSTER_ID>"
}

variable "export_path" {
  description = "Directory on server to store export (dump) files"
  type        = string
  default     = "/backups/mongo/exports"
}

variable "schedule" {
  description = "Whether to schedule the export"
  type        = bool
  default     = false
}

variable "compress" {
  description = "Whether to compress the export file"
  type        = bool
  default     = false
}

variable "include_data" {
  description = "Include actual database data in export (not just schema)"
  type        = bool
  default     = true
}

variable "keep_days" {
  description = "Number of days to keep the exported files"
  type        = number
  default     = 2
}

• Resource definition

/*
  Resource for triggering MongoDB node export (dump) via REST API.
  All fields are parameterized for portability and automation.
*/
resource "restapi_object" "export_database" {
  path = "/dump_mongo_node/"
  data = jsonencode({
    node_id      = "${var.mongo_host_address}:${var.mongo_host_port}"
    type         = "MONGO"
    cluster_id   = var.cluster_id
    schedule     = var.schedule
    compress     = var.compress
    include_data = var.include_data
    export_path  = var.export_path
    keep_days    = var.keep_days
    rest_api     = true
  })
}

• Output block‍

/*
  Output the full API JSON response after triggering the export.
  Use for logs, CI/CD visibility, or follow-up automation.
*/
output "export_response" {
  description = "Raw JSON response from dump_mongo_node"
  value       = restapi_object.export_database.data
}

Step 4: Initialize & Apply

cd integration/terraform/export_database

# Initialize the Terraform working directory and download necessary providers
terraform init

# Apply the configuration, review the planned actions, and confirm execution
terraform apply

# Output the API response for logging or integration with other tools
terraform output export_response

Additional Guidance & Best Practices

• Parameterization: Use Terraform variables for all hostnames, cluster IDs, export paths, and schedule options to enable repeatable, environment-agnostic workflows.
• Security: Store JWT tokens and sensitive data securely (environment variables, secret managers, or Terraform’s sensitive type).
• CI/CD Integration: Automate database exports via your CI/CD pipeline for reliable, versioned, and auditable dumps.
• API Versioning: Check 123cluster API docs regularly to ensure you use the latest compatible endpoints and payloads.
• Logging & Outputs: Capture export job results with Terraform outputs for audit trails and automated follow-up actions (like backup integrity checks or notifications).
• Environment Isolation: Use workspaces for separate development, staging, and production export runs.
• Error Handling: Validate API responses in your automation process and implement robust alerting for export failures.

‍
